Focus on the high-voltage battery system of the Audi e-tron: 95 kWh of energy

The Audi e-tron houses its batteries in a floorpan housing, which is waterproof and crash resistant…

When talking about the production of the impressive Audi e-tron on the Brussels site, the batteries are an intriguing part of the driveline. We take a closer look at it here, and show you some very interesting drawings provided by Audi Media…

Hans Knol ten Bensel

The large lithium-ion battery in the Audi e-tron provides for a range of more than 400 kilometers (248.5 mi) in the WLTP driving cycle. The battery operates with a nominal voltage of 396 volts and stores 95 kWh of energy.

Electric drivetrain in detailed view (ctrl + to enlarge)

The battery system in the Audi e-tron is located beneath the cabin and is 2.28 meters (7.5 ft) long, 1.63 meters (5.3 ft) wide and 34 centimeters (13.4 in) high. It comprises a total of 36 cell modules in square aluminum housings, each of which is roughly the size of a shoe box. They are arranged on two levels, known as “floors” – a longer lower floor and a shorter upper one. At market launch, each module is equipped with twelve pouch cells having a flexible outer skin of aluminum-coated polymer. In the future, Audi will use both technically equivalent prismatic cells in its modular concept, also in terms of a multiple supplier strategy.

Integrated crash structure of the lithium-ion battery housing

The cell modules in the Audi e-tron can reproducibly discharge and charge electricity over a broad temperature and charge status window. The can be densely packed to achieve a very high output and energy density in the volume available.

Cooling the lithium-ion battery during DC charging via the NT cooler

A cooling system of flat aluminum extruded sections divided uniformly into small chambers has the task of maintaining the battery’s high-performance operation over the long term. Heat is exchanged between the cells and the cooling system beneath them via a thermally conductive gel pressed beneath each cell module. In what is a particularly efficient solution, the gel evenly transfers the waste heat to the coolant via the battery housing. The cooling system is first fixed to the bottom of the battery tray with adhesive. To protect the cooling system against stone and road debris, a base plate is installed, also to improve aerodynamics. At assembly, first the batteries/modules on both floors are placed into their locations, then the gel (also called gapfiller) is applied.

Charging of the lithium-ion battery

The battery and all of its parameters, such as charge status, power output and thermal management, is managed by the external battery management controller (BMC). This is located in the occupant cell on the right A-pillar of the Audi e-tron.

Liquid cooled lithium-ion battery, in exploded view one can clearly see the elements, the BJB (Battery Junction Box), the BMC or Battery Management Controllers, the cooling system, and last but not least the modules.

The BMC communicates both with the control units of the electric motors and the cell module controllers (CMC), each of which monitors the current, voltage and temperature of the modules, 3 modules at the time. In the whole battery system, therefore 12 CMC’s are present. The battery junction box (BJB), into which the high-voltage relays and fuses are integrated, is the electrical interface to the vehicle. Enclosed in a die-cast aluminum housing, it is located in the front section of the battery system. Data exchange between the BMC, the CMCs and the BJB is via a separate bus system.

Lithium-ion battery module with twelve pouch cells

Sophisticated measures have been taken to protect the high-voltage battery of the Audi e-tron. A strong enclosing frame of cast aluminum nodes and extruded sections, plus an aluminum plate 3.5 millimeters (0.1 in) thick protect against damage from accidents or curbs. Inside, a framework-like aluminum structure reinforces the battery system. Also comprised of extruded sections, it holds the cell modules like a typecase.

Detail of the pouch type cell

Including the housing with its sophisticated crash structures comprising 47 percent extruded aluminum sections, 36 percent aluminum sheet and 17 percent diecast aluminum parts, the battery system weighs around 700 kilograms (1,543.2 lb). It is bolted to the body structure of the Audi e-tron at 35 points. This increases its torsional rigidity by 27 percent and contributes to the high level of the safety of the Audi e-tron, as does the cooling system bonded to the outside of the battery housing. Compared to a conventional SUV, the Audi e-tron offers 45 percent higher torsional rigidity, a key parameter for precise handling and acoustic comfort…

During production and assembly, utmost care is taken that screws which fix the modules into place do not cause insulation faults, and before the battery unit is cleared for further assembly, the differences in voltage between the cells and the modules are carefully controlled that it meets Audi Premium Standards. Finally leak tests are also carried out, both on the cooling system and the battery. Not less than 8 final tests are performed, before the battery is then partially (re)charged and fit for further assembly in the car.

 Hans Knol ten Bensel

DS designers reveal their art and creativity to the public…

A design studio which works amidst a wide audience, where their 3D models and drawings are made under the eyes of interested viewers? That is what the bold man and women of the DS Design Studio are doing.

These designers are the creative pillar of DS Automobiles, a young car brand whose designs for DS 7 CROSSBACK and DS 3 CROSSBACK are already a benchmark. DS DIVINE, DS E-TENSE and DS X E-TENSE are also the results of a creative process that came about within DS DESIGN STUDIO PARIS

These designers are now leaving their usual work space and setting up over the three floors of DS WORLD PARIS at 33 Rue Francois 1er, Paris.

The DS World Paris is the elegant setting where the public can admire the iconic “DS” or “Déesse”, the godess on wheels, but now also the men and women of the celebrated DS design department will be at work under their eyes…

There, the men and women of DS Automobiles design under the direction of Thierry Metroz, DS Design director, will be revealing the innovative projects they’re working on and sharing their secrets through “CONFIDENCE The art of the senses”.

More than an exhibition, this is a residency of artists, brought to life by DS Automobiles designers who are on hand to explain their jobs, present their work and talk with visitors.

Indeed, the men and women of DS DESIGN STUDIO PARIS are on hand throughout the event to explain their work and answer visitors’ questions.

Some confidentiality restrictions have been lifted so they can reveal additional secrets. The work of the 60 people who make up the DS DESIGN STUDIO PARIS is presented by the different teams: exterior design, interior, ProLab, VLab, modellers, colour and material workshops and upholsterers.

The brand wants them to share their inspiration and most recent work to cast a new light on the design and build of a car.

So, if you are interested to see these design artists at work, we give you here some practical information: “CONFIDENCE The art of the senses” is held from 22 March to 23 April 2019 at DS WORLD PARIS, 33 Rue Francois 1er, Paris.

Hans Knol ten Bensel

We drove the Jaguar F-Pace: a thoroughbred feline fit for all roads and uses…

We all know that SUV’s are all the rage, and are becoming ever more popular. No small wonder then that this stylish Jaguar SUV, launched in 2015, is the bestseller of the iconic brand. But then, you may ask with us, is this popular SUV still remaining a true Jaguar, combining pace (performance) with grace and space? Will the growl of its powerful engine lift your spirits, will its chassis seduce you with its graceful handling and comfort, will the beautiful body and interior put you in the exquisite mood and ambiance which only a Jaguar can convey? Just read further…

Hans Knol ten Bensel

Feline contours

Looking at the photos you will agree, this F-Pace has the looks so unique to Jaguar. The waistline which ends in a higher tail contour, reminiscent of the rear end of the Jaguar E-type, where its high mounted rear bumpers also followed the waistline, the well rounded curves, the proportions of the wheel arches, well integrated in the fluent lines of the whole body, the subtle central bulge on the engine hood, all this is well and truly Jaguar.

In the interior, the digital age and the utmost attention to passive safety has put its own boundaries and accents, and so, alas, you will not find a wood rimmed steering wheel, nor does it lay thinly rimmed in your hands, the trend of times has commanded otherwise. But once the digital instrumentation lights up on the screens, one sees the familiar big round dials, and the classic lettering in the instruments, white on black, of, well, vintage Jaguars. As readers know, your servant is the proud owner of a Mk II 3,4 litre Jag, and yes, I felt well at home in this one.

The latest generation digital infotainment screens and functions are also intuitive and the proverbial breeze to use, and rank among the very best you will find in any car nowadays. The centre console is wide – again a celebrated Jaguar tradition- and houses the ergonomic rotary gear selector of the excellent 8- speed ZF auto box, and one just has to turn the column to choose the right function, and it will discreetly descend into its mount when you stop the car and engine, so neat and practical, and (luck has it) so unique to Jaguar. Going from “D” to “R”everse is just a short twist on the column selector, and that is soo clever!

Abundant, smooth, growling power…

The heart of any car is its engine, and in a Jaguar it simply HAS to be powerful, with abundant torque and pulling power, from low revs onwards, and on top of all that it has to develop that deep, feline sound. No small feat for a Diesel engine. But then, this is a V6 (yes, to me, a Jaguar is only a Jag with a SIX cylinder engine, sorry…) and it has 3 litre of displacement. So there are 300 HP available, at 4000 rpm. Of this, the Jaguar E-Type could only dream. With on top of all that 700 Nm of torque in store for that necessary feline punch, and this at merely 2000 rpm. So the outright performance is truly Jaguar, and indeed, the classic E-type could hardly match its 0 to 100 km/h acceleration of 6.2 sec. It would also have needed the right rear tyre size and final drive ratio to reach the same top speed of 241 km/h which this F-pace is capable of.

The thermal efficiency of a (large) Diesel is legendary, and shows abundantly here too that they belong into the larger SUV’s when there is no electrified or hybrid propulsion present in the drivetrain. It took just a restrained driving style with the engine humming along around 1000 rpm at urban legal speeds, to reach consumption averages between 7,4 and 7,8 liters/100 km in dense urban traffic. A petrol engine of similar size and power does not come even close to these figures in such a 4,7 metre SUV with a kerb weight of 1884 kg. The ingenium technology in these all aluminium engines offers low friction, and all this truly pays off.

We couldn’t resist making this line drawing version of the inconic Jaguar badge on the front grille. This F-Pace is indeed a true Jaguar…

Handling like a thoroughbred

As shares some of its architecture with the XE and XF, it handles very car-like. Of course, you can choose between driving modes that stiffen the suspension and boost steering response, but even in normal settings the F-type handles like a dream, displaying also very little body roll for an SUV of this weight and size. With the larger engines, the F-type offers standard 4WD, and this sends all the power to the rear wheels most of the time, with occasionally 20 pct sent to the front. On slippery surfaces, up to 50 % of the pulling power can be sent to the front wheels.

 A key ingredient to these impeccable road manners is its lightweight construction. Don’t forget that 80 pct of the body, excluding the doors, bonnet and plastic tailgate, is made of aluminium. Then there is the near perfect 50/50 weight distribution, an integral link rear suspension, and the aluminium double wishbone suspension at the front which is closely following the F-type setup. Electronics will analyze steering movements up to 500 times per second, body movements up to a 100 times per second. Do we need to say more? This Jaguar is in all its sportiness graceful and comfortable, never too hard, even in this sport mode.

Everyday practicality

The F-type is an SUV, and that means born and built for the modern day mobile couple and family. It easily seats five adults, has a minimum trunk volume of a very decent 650 liters, space for ski’s, toddler isofix seat anchors, electric tailgate, you name it. All thinkable driver assistance options can be had, the infotainment supports Apple and Android Car Play, the sound system is nothing short of superb.

Conclusion

The F-Pace is Jaguar’s bestseller, and for all the right reasons. It has feline, beautifully curved and timeless looks, both inside and out, displays uncanny panache behind the wheel, handles well balanced and displays all the growling Jaguar power you could ever wish for. Don’t forget also, this car is voted World Car of the Year 2017 en World Car Design of the Year 2017; Thi year, the model range has been extended with the
300 SPORT and Chequered Flag. In the diesel version it is as frugal as modern times command it, and if you decide to go green all the way, then Jaguar as the latest I-Pace, which is also a formidable looking car with many (E-) promises.

Needless to say we are very keen to lay our hands on one, but for the time being, and indeed for many years to come, this F-Pace will fulfil everything you could possibly wish of a Jaguar, and this better than ever.

Hans Knol ten Bensel

FCA CEO Sergio Marchionne: A genial automotive manager has passed away…



He was born in Chieti, on the Italian Adriatic coast, as the son of a carabiniere or state police officer, on June 17, 1952. His father was a wise man, with a keen sense of money and savings, and he had invested enough to retire early. He decided to give his family a bright future in Canada. When young Sergio was 14, they moved across the ocean to Toronto.

His studies gave him a broad view…

Sergio Marchionne, the CEO of FCA, was not altogether a pure “auto” person, rather on the contrary. This prepared him to become an outstanding manager. Just look at what he studied. He started at the University of Toronto with philosophy, earned himself a master’s degree in business administration at the University of Windsor, in Ontario, and finally obtained a law degree in 1983 at the Osgoode Hall of York University. He began his career as … a tax specialist.

Luca De Meo, CEO Fiat Automobiles, and Sergio Marchionne, then CEO Fiat Group Automobiles, with the Fiat 500 (2007)

Broad business experience made him an ideal crisis manager…

This keen sense for numbers and figures made him the ideal manager to work out successful turnarounds and save companies from the brink. He moved to a metals trading firm and was also very successful in a trade services company. A broad experience in trading and business together with an excellent mastery of English, French and Italian gave him many possibilities, and having forged himself an enviable reputation of a crisis manager, he was spotted by the Agnelli family, seen as the right person on the right place to save the ailing Fiat company. The fact that he had a broad non-automotive experience was rather seen as an asset. He was appointed CEO of Fiat in 2004, and started with the necessary reforms to lighten the debt burden as soon as possible. He knew soon enough about the existing deal between G.M. and Fiat, and first tried to force G.M. into purchasing Fiat. General Motors had other plans, so Marchionne obtained 2 billion USD in compensation from G.M. to allow them to step out of the alliance. Money he put to good use to rejuvenate the model range, with the 500 being the all-time star.

Mike Manley and Sergio Marchionne with the new Jeep Renegade (09/2014)

A second success with Chrysler/Jeep…

Marchionne knew that automakers with global ambitions also need to have a solid base in the US market, and amidst the 2008 crisis he made clear to the US Treasury that he would be prepared to take control of Chrysler and revive it using the excellent state of the art Fiat group technology he had at his disposal.

He also knew very well that the Chrysler creditors and unions were putting hard pressure on the US Treasury, so he decided to up the ante to the beleaguered US government to ask them to hand over Chrysler to him… for free.

He succeeded, and the good results are known to everybody. Especially the dramatic turnaround of Jeep made the FCA Group now a profitable giant.

He was planning to retire in 2019, but fate has decided otherwise, as a result of unexpected complications after a shoulder surgery on July 5.

Fate has it too that his last official public appearance on last June 26, was to hand over in Rome at a ceremony in the grounds of the Carabinieri High Command, in the presence of Commander-in-Chief Giovanni Nistri, the liveried Jeep Wrangler.(see the accompanying photo).

He is succeeded by Mike Manley, (see photo above),  the head of Fiat Chrysler’s North America operations and its Jeep and Ram truck brands.

Hans Knol ten Bensel





A feast for the senses: we visited BMW Artville in Knokke

BMW’s very first Art Car which also actually raced: the BMW 3.0 CSL created by Alexander Calder…

Summer is the time to let the creative spirits flow, and enjoy nature and art. An ideal time to regenerate body and mind. Besides enjoying the outdoors, enriching experiences like a visit to exhibitions and art galleries are always firmly on the agenda of your servant. Therefore a visit to the BMW Artville in Knokke (see our previous report in these columns) was a must, and we let you enjoy it here…

Hans Knol ten Bensel

Jan Fabre takes centre stage…

An “autoportrait”  sculpture of Jan Fabre himself adorns the BMW Artville beach…

As we announced already in our previous report, artist Jan Fabre showed a very intriguing “performance” film, displayed on five different screens simultaneously, titled “Schande übers ganze Erdenreich”. The performance of priestess Stella Höttler is very gripping indeed. For photos of this performance film we refer to our previous report in these columns. The two turtles she carries in both hands during her ecstatic performances are for Jan Fabre the “oracle stones” because their shields carry the weight and the memory of centuries. Especially the shield is an object of fascination that breathes life into dream images. The shield and its geometric patterns were already used in the Oracle of Delphi…

A landmark on the Knokke beach: BMW Artville

In this performance, “Schande übers ganze Erdenreich”, the perforer implores the gods to teach mankind to treat the inheritance of the world more kindly.

Jan Fabre is fascinated by the relations man-animal and animal-man and by the analogy in their nomadic nature. As an artist, he wants to put into language the mystery of the cycle of death, decay, birth and renaissance. In this quest, he uses as his inner compass the synergy between his personal instinct, intelligence and intuition. He constantly searches the changing face of existence.

This is also seen in his series of fourteen new skulls, clad in ballpoint ink, which hold the skeletons of a bird or animal in their mouth. It evokes the “Blue Hour” of Jean-Henri Fabre, where at daybreak the blue night is chased away. Just as the night is eternally changed into day, life is also a constant stream of (re)birth and death.

‘BMW Artville – Jan Fabre curated by BOZAR’ announces two future projects of the artist in BOZAR. “Schande übers Ganze Erdenreich!” takes place in the framework of the Theodoor van Loon exhibition (December 2018-January 2019). The art works from the cycle “The Hour Blue” are the harbinger of Fabre’s solo exhibition “The years of the Hour Blue” (May-September 2021).

The BMW Art Car Collection

On BMW Artville, BMW Belux presents two cars from the BMW ART CAR Collection. We stood admiringly eye to eye with the BMW 3.0 CSL created by Alexander Calder (1975).

Alexander Calder’s design was executed by car painting specialist W. Maurer…

Using the creativity of an artist on a (racing) car was the brainchild of racing driver, art lover and auctioneer Hervé Poulain, who actually raced this car in Le Mans, together with the American Sam Posey and Jean Guichet. After 7 hours, the car had to give up due to a defective prop shaft. The car was never raced again and has been on diplay since then.

The unique collection of BMW Art Cars consists today of 19 cars, designed by the following artists: Alexander Calder (1975), Roy Lichtenstein (1976), Frank Stella (1977), Andy Warhol (1979), Ernst Fuchs (1982), Robert Rauschenberg (1986), Ken Done (1989), Michael Jagamara Nelson (1989), Matazo Kayama (1990), César Manrique (1990), A.R. Penck (1991), Esther Mahlangu (1991), Sandro Chia (1992), David Hockney (1995), Jenny Holzer (1999), Olafur Eliasson (2007), Jeff Koons (2010), John Baldessari (2016) en Cao Fei with her BMW M6 GT3.(2017). Artists for the BMW Art Car Project are chosen by a panel of international judges.

According to Thomas Girst, who has been in charge of the BMW Art Cars project since 2004, the purpose of the project has changed over time: “In the beginning the cars were raced. There wasn’t much of a public relations effort around them… Since then, some of the Art Cars have been used in advertisements to show that BMW is a player in the arts.”

Besides the stunning i8 roadster, BMW Belux Corporate Communications Officer Saschia De Rudder kindly showed us two forthcoming BMW models in preview, which formed also a highlight of this artful experience on the sunny Knokke beach and stylish BMW Artville premises… We just let you enjoy the photos here!

Hans Knol ten Bensel







The genius who designed the D Type Auto Union: Robert Eberan von Eberhorst

We treat you this time, dear reader, on a following story about famous men who changed motorsport and/or made such an important contribution to the development of the automobile, that the automotive world has never been the same again since then. Such a man was the Austrian nobleman Robert Eberan von Eberhorst. He made his mark as a formidable engineer not only before WW2, but also throughout the war and also in the fifties, and one of his post-war creations, the Aston Martin DB3 sports racing car, is still raced in historic sporting events, right until this day…

But there is so much more, just read on!

Hans Knol ten Bensel

Continue reading “The genius who designed the D Type Auto Union: Robert Eberan von Eberhorst”

All is well again with our BMW Z3…

Ready again for beautiful drives in summer Sunshine…

At the moment of writing, the experts at BMW Jorssen made a swift and expert repair and brought again a broad smile on our face: we are enjoying again undisturbed roadster pleasure in this magnificent summer weather we are having presently.

We suspected rightly some troubles with the master and/or slave cylinder, and we were rather optimistic in believing that bleeding of the system might solve the problems, but alas, when all hydraulic pressure is lost in the system, most of the time more serious things are amiss.

A broken and leaking FAG-made clutch slave cylinder was at fault…

The experts at Jorssen soon discovered that the clutch slave cylinder was indeed badly leaking and faulty. This slave cylinder is attached with two nuts on the transmission and actuates the clutch. It is manufactured by FAG, which actually belongs to the Schaeffler Group. The FAG brand dates from 1905 and stands for “Fishers Aktien-Gesellschaft.”

The clutch slave cylinder is bolted with two nuts on the tranmission…

The two brothers Wilhelm and Georg Schaeffler who founded in 1946 INA in Herzogenaurach, took over FAG in 2002 and their firm now has grown to a worldwide giant – the second largest producer of needle bearings in the world – and manufactures amongst other things precision parts like needle bearings, hydraulic valve lifters, hydraulic variable valve timing systems. Did you know that the London Millennium Wheel (also called the London Eye), runs on two massive frictionless bearings made by FAG?

In 2003 LuK (clutches), INA and FAG form the “Schaeffler Group”. It is actually the largest German company which is still exclusively family owned.

But back to our BMW Z3. Because of the leakage, it was feared that some oil would have leaked on the clutch, but I never noticed anything indicating this, and indeed, fortunately the clutch functions perfectly and very progressively.

When the slave cylinder is removed, (see the two loose bolts) one sees clearly the hole where the cylinder is lodged, and where it pushes the clutch in open position with its pin. When mounting this cylinder, one has to be careful that this pin is perfectly centered

The repair bill was very reasonable indeed, with only 20,8 Euros charged for actually removing the old and mounting the new pump, with most of the work – costing almost 89 Euros – being involved in bleeding the hydraulic clutch system. The FAG slave cylinder itself set us back some 129 Euros. We indicate here that these prices here are ex VAT, so 21 % VAT had to be added.

Of course, the hydraulic brake fluid – DOT4 spec- was replaced, as the hydraulic system of the clutch takes its hydraulic fluid from the brake reservoir, and the people at Jorssen was even were so meticulous to also top up  coolant and windscreen spray fluid reservoirs.

The car was repaired in a day, so needless to say we were very pleased with the very swift service.

We will keep you posted, dear reader, on the further life of our Z3, and in the meantime we plan to contact the press officer in our country of the Schaeffler Group, with some questions about service life and eventual maintenance of their FAG clutch slave cylinders… we are very curious indeed!

Hans Knol ten Bensel



More power and zest for the Mazda MX-5 Roadster…

At the moment of writing we are driving the very entertaining and refined Mazda CX-5, and we hear from the dynamic PR-Manager Peter Gemoets that Mazda is launching an update of its bestselling roadster, enhancing the inimitable thrill of the Jinba Ittai driving experience.

Jinba ittai, or the thrill of perfect unity between the horse and its rider with the arch…

For those who are not familiar with this concept and do not know what it means, we tell you here that Jinba ittai (人馬一体, “person [and] horse [as] one body”) is a Japanese four-character compound, describing unity of horse and rider which is pertinent to Yabusame, Japanese mounted archery. We could not resist the temptation to make a drawing of one of those valiant warrior/riders with their big arches, galloping on their horses…

Hirotaka Kanazawa: “it all comes down to the relationship between the car and the driver”

A beautiful symbol, indeed evoking what Mazda is striving to reach with its CX-5, namely the unity between the driver and its four wheeled mount, the MX-5. As we told you already in our test report of the MX-5, it is one of those cars which delivers you tons of driving pleasure. This is also precisely what people like Hirotaka Kanazawa, the managing executive officer of Mazda Japan, and responsible for car development, tells us: “we firmly believe that when we make a fantastic car, it all comes down to the relationship between the car and the driver”. We show you here his photo, and an image taken in the research and development department, where the all important relationship and “feel” is tested between steering wheel and gear lever…

The “feel” of the car with your hands on the wheel and the gearlever… this is what they test at the Mazda development centre…

The 1.5 and 2.0-litre SKYACTIV-G petrol engines have further improved combustion and greater torque now, and comply with new WLTP/RDE test cycle, meeting Euro 6d Temp emission regulations. Both powertrains benefit from refined acceleration control to minimise lag between throttle applications and vehicle response.

The SKYACTIV-G 2.0 engine is now higher-revving and acoustically further tuned, with maximum engine speed raised from 6,800 to 7,500 rpm, maximum horsepower increased from 160 to 184 PS @ 7,000 rpm, and maximum torque from 200 to 205 Nm @ 4,000 rpm.

Five new i-ACTIVSENSE safety technologies are also introduced: Advanced Smart City Brake Support which detects vehicles and pedestrians ahead and helps avoid collisions, and Smart City Brake Support (Reverse) which detects vehicles and obstacles behind, as well as Driver Attention Alert, a Traffic Sign Recognition System and a Rear View Camera. This we also enjoy now in the new CX-5 we are testing.

The award-winning KODO-Soul of Motion design is further enriched through a darker paint finish for both 16″ and 17″ alloy wheels, and the eye is further seduced with the availability of a new brown canopy colour for soft-top models.

Hans Knol ten Bensel



Alfa Romeo wins historic Mille Miglia 2018

Here you see GIOLITO Roberto and GIUDICI David, Starting number 31, in their 1930 Alfa Romeo 6C 1750 GS… on the grounds of the Museo Storico, during the event.

As we told your earlier, dear reader, Alfa was present in strength at the latest edition of this beautiful event. The course led even to the Museo Storico grounds, and the Alfa’s which participated were equally breathtaking. Indeed, the race caravan paid a celebratory visit to the Museo Storico Alfa Romeo at Arese, where time trials were held on the internal circuit.

But besides meticulous cars, it also pays of to prepare yourself thoroughly for this regularity event. Know the course and the stages very well, and train yourself in driving to the (hundreds of a )second.

Here you see my drawing of the winners, receiving the chequered flag . For a better view, press ctrl + to or pinch enlarge it…

This is what the winners did, TONCONOGY Juan and RUFFINI Barbara, in their 1933 ALFA ROMEO 6C 1500 GS “TESTA FISSA”, starting number 85. You see them here on my drawing here joyously receiving the finish flag, with the second official presenting already the coveted champagne bottle. Miss Barbara Ruffini is already holding her left hand on the door to jump out of the car and collect her winner’s prizes.

This was not the only success of the formidable Alfa’s.

In second place, just eight penalty points behind the victor, there was the stunning 6C 1500 Super Sport dating from 1928, with coachwork by Stabilimenti Farina. This was an official car from the FCA Heritage collection, which is normally on display at the Museo Storico Alfa Romeo, driven by Giovanni Moceri with co-driver Daniele Bonetti, with starting number 30. See here the photo above.

In third place, the 1929 Alfa Romeo 6C 1750 SS Zagato of Vesco-Guerini, starting number 39.

It is very touching to see that 50 years after their 1928 victory, an Alfa is again on the winner’s podium in this iconic Mille Miglia.

I couldn’t resist making a drawing of the glorious moment when the winners drove on the podium, and present you also some more photos of the other winners and Alfa’s in the Mille Miglia 2018…

Hans Knol ten Bensel

Ettore Bugatti and his son Jean: two creators of a legend…

Having drawn the magnificent Bugatti engines, one is of course also fascinated by its creators. So I decided to make some detailed and realistic pen drawings of father and son – Ettore and Jean – on important occasions. The young Jean sits next to his father in 1924 at the Lyon Grand Prix, in a type 35. His father is then 43, and Jean is 15…

Ettore Bugatti was to shape automotive history forever – with his formidable artistic and technical genius. He was born on 15 September 1881 in Milan, into a very artistic family. His father was an important Art Nouveau furniture and jewelry designer, his brother Rembrandt Bugatti a sculptor, his grandfather an architect and sculptor.

Ettore turned his interest to cars. In 1909, his son Jean was born, and in that same year Bugatti established his legendary automobile company, Automobiles E. Bugatti, in 1909 in the then German town of Molsheim in the Alsace region. He had married Barbara Maria Giuseppina Mascherpa. Besides Jean, the marriage produced two daughters, L’Ébé in 1903 and Lidia in 1907, and another son, Roland in 1922.

Of course, son Jean was soon to follow in his father’s footsteps. Jean designed in de mould and tradition set by his father the Bugatti’s Type 50 and 51 and the stunning Bugatti 57, with their beautiful twin cam engines. When Jean reached the age of 27, Ettore retires, and leaves the factory and its management to Jean. Unfortunately, the kind and genial Jean kills himself on 11 august 1939 behind the wheel of the 57C which had just won Le Mans,  running at more than 200 km/h against a platan on a country road in Duppingheim.



I drew this charming and very elegant man here when he was 23.

Since then, things went downhill for Ettore and the famous brand. World War II ruined his factory in Molsheim, and his wife Barbara died in 1944. But Ettore Bugatti remarried in 1946, to Geneviève Marguerite Delcuze. This union and marriage had produced already a daughter, Thérèse in 1942 and later a son, Michel in 1945.

Ettore was also a lover of horses and yachts. He had bought a magnificent one after the war, but contracted the flu while visiting it at the wharf.  Having contracted pneumonia, he subsequently went into a deep coma. He was almost certainly unaware of the court decision whereby his property in Alsace, which had been confiscated by the state as retribution caused by his Italian origins, were restored to him on 20 June 1947: Ettore Bugatti died just over two months later, on 21 August without having recovered consciousness.
